Narrow- Bezel AiP Hand Wave Gesture Recognition (Counting) mmWave Sensor
XenG103GS is a 24GHz AiP mmWave gesture-sensing reference design built around the ICL111A SoC, integrating hand-wave recognition and human proximity wake-up functions. Based on FMCW technology and target recognition algorithms, it accurately detects hand wave gestures (1~20 cm) and measures human distance (0.2 ~ 4 m). It enables proximity-based wake-up and gesture control for smart devices, making it ideal for applications such as smart displays, smart home systems, smart appliances, and smart kitchen and bath products.
Features
- Gesture recognition: Non-contact control with high-precision hand wave detection.
- Convenient Development: Integrated human sensing and distance measurement function with multi-parameter configuration.
- Accurate Ranging: Human distance measurement accuracy of ±20 cm with configurable sensing range.
- Interference Shielding: Precisely defined gesture recognition zone to block out interference beyond the designated area.
Specifications
Illustration of Detection Range
Visualization Tools
Visualisation Tool for Hand Gesture Recognition
Applicable to Various Scenarios
| title | category | version | size | Publish Time | action |
|---|---|---|---|---|---|
| Hand Gesture Recognition Visualization Tool |
Document
| title | category | version | size | Publish Time | action |
|---|---|---|---|---|---|
| ICL Product Brochure2026.8 | |||||
| Product Specifications_XenG101GS_XenG103GS Product Specifications | |||||
| Application Note_mmWave Sensor Radome Design Guide | |||||
| User Manual_XenG101GS_XenG103GS User Manual | |||||
| PCB Layout_XenG103GS | |||||
| Schematics-XenG103GS |
